Detailed Image:
Product Introduction:
Material Grade
Austenitic stainless steel (1.4404 / 316L) with low carbon content (≤0.03%) for superior corrosion resistance.
Surface Finish
Precision polished (smooth/BA finish) for reduced friction, improved hygiene, and aesthetic appeal.
Mechanical Properties
High strength (≥485 MPa tensile) with excellent toughness and weldability.
Corrosion Resistance
Resists pitting, acids, and chlorides (ideal for marine/chemical environments).
Dimensional Range
Customizable OD/WT with tight tolerances for precision applications.
Key Features:
High-quality stainless steel material
Excellent corrosion resistance
Suitable for high-temperature and high-pressure environments
Smooth internal and external surfaces
Perfect dimensional consistency
Standard Grade Table:
| Standard Grade | Material Composition | Tensile Strength (Minimum) | Yield Strength | Elongation |
|---|---|---|---|---|
| 1.4301 | 18% Cr, 8% Ni | 500 MPa | 200 MPa | 35% |
| 1.4404 | 17% Cr, 11% Ni, 2% Mo | 530 MPa | 220 MPa | 35% |
| 1.4571 | 17% Cr, 12% Ni, 2% Mo, 0.05% C | 520 MPa | 210 MPa | 35% |
| 1.4462 | 22% Cr, 5% Ni, 3% Mo | 700 MPa | 450 MPa | 25% |
Applications:
EN10216-5 Stainless Steel Tubes find wide applications in various industries:
Chemical Industry: for the transport of corrosive media.
Oil and Gas Industry: for downhole and topside applications.
Food Processing Industry: suitable for food handling and conveyance.
Pharmaceutical Industry: for drug manufacturing and transport.
Mechanical Engineering: for high-pressure fluid conveyance.
Customization Options:
We offer a variety of sizes and lengths for EN10216-5 Stainless Steel Tubes to meet the requirements of different applications. We can also provide special surface treatments, such as polishing and sandblasting, to cater to customer specifications.
Quality Assurance:
Our EN10216-5 Stainless Steel Tubes conform to international quality standards and undergo rigorous quality control and testing to ensure product reliability and performance.
No matter what your application requires, EN10216-5 Stainless Steel Tubes are an excellent choice with outstanding corrosion resistance and strength, suitable for a variety of challenging environments. Contact our sales team for more information and customization options.
